WHX-1000 optical microscope with super depth of field
Retail Price
Market price
Weight
kg
Stock surplus
隐藏域元素占位
- Product Description
-
- Commodity name: WHX-1000 optical microscope with super depth of field
WHX-1000 super depth of field microscope We continue to pursue the application of new technologies and intelligent convenience, so that the micro-world beautiful presentation, so that the operation is easier, so that difficulties no longer hinder your work. We continue to work hard and will continue to pursue the continuous progress of the microscope to create the ideal visual observation equipment and intelligent detection equipment for customers.
■ Product features
1. Multiple magnification objective lens selection
Can be replaced5 times, 10 times, 20 times, 50 times flat field objective lens to adapt to different magnification.
2. Standard 10 times high-definition objective lens
Product default assembly 10X Flat Field Objective. Working distance 17.7mm, bore 0.30mm. The diameter of the lens interface is 20.2mm. 5X, 20X and 50X objectives can be selected as required.
3. The lens body supports 0.7-5 times optical magnification
4. Optional conversion nose wheel
Can be added4-hole position conversion nose wheel, 5 times, 10 times, 20 times and 50 times objective lenses are installed in 4 holes respectively.
5. Magnification Table
Various specifications of the lens inMagnification under 24-inch monitor
(Display Size475*268mm)
Lens optical magnification
Objective lens magnification
5X
10X
20X
50X
0.7
80 times
160 times
300 times
800 times
1
100 times
200 times
400 times
1000 times
2
200 times
400 times
800 times
2000 times
3
300 times
600 times
1200 times
3000 times
4
400 times
800 times
1600 times
4000 times
5
500 times
1000 times
2000 times
5000 times
6. Highlight ED coaxial light source
High brightness coaxial point light source, power 5W, reliable and natural heat dissipation design,stable operation.
7. Precision XY mobile stage
Size of platform 200*180mm, travel range 100*109mm. XY movement manual, movement accuracy of 0.01mm.
8. High-precision Z-axis drive
The Z axis is driven by a high-precision stepping motor, and the accurate grating ruler is read to measure the distance, with an accuracy of 0.1um, which can ensure the accuracy of the measurement size.
9. Ultra-clear HDMI camera
Camera parameters:
chip structure
FPGA ARM
Operating System
INUX 3.10
kernel structure
dual coreCortex-A9
main frequency speed
1Ghz
Optical Dimensions
1/1.2 "or 1/2" optional
Points identification Rate
1920 × 1080
Pixel Size
5.8*5.8um
Frame Rate
30fps
Color adjustment
RGB three-channel individual adjustment
White. Ping Heng
Auto Exposure
Screen Mirroring
Up and down mirroring, left and right mirroring
HDR
Support wide dynamic
Video Interface
HDMI
Network Interface
1000Mbps
Operating voltage
DC 12v
10, Stereoscopic 3D Imaging
The depth of field synthesis technology is used to construct three-dimensional graphics. Graphics can be720 degree tow rotation view.
The cutting line can be adjusted at any angle and any position to generate a profile.
11. Profile height measurement
12. Chromatographic Height Chart
It is convenient for customers to clearly see the three-dimensional height difference, and the chromatographic height map can also be used. 720 degree drag viewing.
13. The cutting line can be dragged at any angle
14. Ultra-high precision image sampling settings
Maximum Sampling Picture 200 sheets
Minimum sampling spacing 0.1um
Selectable filter to filter out interference noise
Fast sampling speed
Electric B- shaft, can provide six up and down running speed
15. Fast generation of super depth of field images
16, convenient data and image report output.
The system exports measurement data,3D graphics, section graphics to the same Exce file, easy to observe the analysis and comparison.
Attached1 Top view
Attached2 Three-dimensional diagram
AttachedSection 3
■ Technical parameters
Lens parameters
Magnification
Minimum0.75X
Max.5.25X
Zoom ratio
1:7(0.75x-5.25x)
Depth of field
0.95mm
0.085mm
Resolution
7.5um
2um
field of view
1/3"Sensor
4.7 × 6.3mm
0.68 × 0.19mm
1/2"Sensor
6.3 × 8.5mm
0.91 × 1.2mm
2/3"Sensor
8.7 × 11.7mm
1.2 × 1.6mm
10X Objective (Standard)
Working distance
Resolution
11mm
0.9um
Whole machine parameters
Resolution
1920*1080
Pixel Size
5.8*5.8um
Size of target surface
1/1.2”
Frame Rate
30 frames/s
Auto White Balance
Auto White Balance
Auto Exposure
Auto Exposure
Image Mirroring
Mirror Up and Down left and right mirror
Measurement accuracy
Maximum measurement accuracy6um, repeated measurement accuracy 3um (standard objective)
Number of pictures collected
3-200 sheets
Z-axis accuracy
0.1um
Size of platform
220*180mm
Platform travel
109*100mm
Z-axis travel
70mm
Working height
0.5-70mm
Power
DC 12V2A
Product size
260*320*450
Weight
13Kg
Working temperature
-10 ℃ -70 ℃
