- Product Description
-
- Commodity name: WJY2000 full touch screen document tester
WJY-2000 full touch screen document inspection instrument is an efficient and stable document inspection equipment, 17-inch touch screen and wireless keyboard and mouse operation, support image and data storage and printing. The equipment can carry out image stitching comparison, gray value measurement, depth of field synthesis, fuzzy image processing, etc., and is suitable for various inspection scenarios such as document defacement, alteration and masking. In addition, it also has functions such as laser detection and holographic pattern detection, and is a professional tool in the field of document inspection.
Scope of inspection
Document checker is widely used in document defacement, alteration and cover-up, addition and repair, fading and forgery, encryption of documents, seals and bills, fluorescence inspection, handwriting indentation, anti-counterfeiting identification, etc.
■ Features:
- 17Inch touch screen machine operation, wireless keyboard and mouse, program control, stable quality, easy to use.
- External real-time liquid crystal display current excitation, cut-off filter wavelength, three-door design, convenient for large inspection material observation.
- HDMIt can store all the images and data obtained by the document detector during the detection process, and can cooperate with the printer to print the required images with high definition live wire.
- The instrument can carry out horizontal, vertical or universal mosaic comparison of the detected two images, overlapping ghost comparison image cutting comparison, and still images and dynamic images can be compared in real time.
- It can measure the absorbance of the chromaticity gray reflection of any specified point or area in the image, and can automatically synthesize the depth of field, blur image processing, geometric correction of deformed image, and fast image processing.
- Can be color gray conversion, color merging, color separation, color filtering.
- Writing order, stamp backbone extraction, curve and linear image shaping, image measurement and labeling, mirroring and other image processing.
- With variable light ink observation, laser detection, holographic pattern detection function.
- Ring lamp4Band segment observation.
■ Main product configuration：
1. light source:
- Excitation light source: ≥313nm、 ≥415nm、 ≥450nm、 ≥490nm、 ≥530nm、 ≥570nm、 ≥600nm, and combined light ≥125species (reflected in the test report).
- Receiving filter: ≥000nm、 ≥650nm、 ≥700nm、 ≥750nm、 ≥780nm、 ≥800nm、 ≥900nm, cut-off filter automatic switching, button operation, convenient and fast, external LCD screen real-time display of the current cut-off filter wavelength.
2. touch screen one machine:The body comes with a 17-inch touch screen, built-in image capture card, HDM, USB port and external equipment can be easily connected, print. Built-in touch screen computer, genuine criminal investigation image processing software, touch pen fine area selection, wireless keyboard and mouse control, can support multimedia LAN teaching.
3. stage:Can rotate 360 degrees, fully transparent K9 glass, glass, magnetic pressure block.
4. camera system:Integrated high-definition digital camera: USB 3.0 interface; No compression and lossless video transmission, 1/2.8 "2MP CMOS image sensor; 30 times optical zoom (4.3~129mm) and 12 times digital zoom; Full HD video output up to 1080 p60; Video support: WINDOWS, Linux; Image imaging does not deform, such as seals, etc.
5. genuine criminal investigation image processing software:
- The storage/printing function can store all the images and data obtained by the document detector during the inspection, and can cooperate with the printer to print out the required images.
- The comparison function can splice and compare the detected two images in horizontal and vertical directions or overlap and compare;Static and dynamic images can be compared in real time.
- The gray value measurement can measure the gray value of any specified point or area in the image. The gray scale change under each detection condition can be displayed in the form of curve. This method is particularly useful for identifying small gray-scale differences between different characters that are difficult for human eyes to detect in images formed by the inspected documents.
- Depth of field automatic synthesis, fuzzy image processing.
- Motion blur processing and deformation image geometric correction, fast image processing.
- Can be reflective absorbance measurement, image measurement and labeling, stamp backbone extraction, curve and linear image shaping, universal cutting comparison, image ghosting and other multi-mode selection and other image processing;
